Super SHade 52S-1 on Clear Triple Low-E IGU

· Visible Light Transmission (VLT): 49%

· External Reflectivity: 16%

· Internal Reflectivity: 12%

· U-Value (W.M2/℃): 1.62

· Solar Heat Gain Co-efficient (SGHC): 0.24

The above data is based on a 6mm+12mm Air Gap+6mm Glass makeup. Varying thicknesses will results in slightly varied performance.

· Smallest Size: 300mm x 300mm

· Max Size: 2400mm x 5800mm

· Residential Windows and Doors: Super SHade is perfect for homeowners seeking the best energy efficiency and a modern, stylish look. It’s ideal for windows, doors, and skylights, providing both high performance and a sophisticated appearance with its neutral grey tint.

· Commercial Buildings: Super SHade is an excellent choice for office buildings, hotels, and retail spaces that prioritize energy efficiency while maintaining a sleek, professional aesthetic. Its advanced performance helps reduce energy costs, while its neutral grey color enhances the design.

· Large-Scale Facades and Curtain Walls: For buildings with extensive glass facades or curtain walls, SuperShade offers superior thermal insulation and light control, helping to create a more comfortable indoor environment while achieving a modern, contemporary look.

· Skylights and Roof Glazing: Super SHade is ideal for skylights and overhead glazing, offering optimal light control, heat reduction, and energy savings while maintaining a clear, elegant view with its light grey tint.

· Public and Institutional Buildings: Super SHade is perfect for schools, hospitals, and government buildings where energy efficiency, occupant comfort, and safety are paramount. The high performance and neutral grey tint make it an attractive and practical choice for large glass installations.

· Triple Low-E Technology: Super SHade features an advanced triple Low-E (Low-Emissivity) coating, providing maximum insulation by reflecting heat back into the building during cold months and reducing solar heat gain in the summer. This ensures optimal thermal performance and significantly lowers energy costs.

· Best-in-Class Energy Efficiency: Designed for maximum energy savings, Super SHade minimizes the need for heating and cooling, making it ideal for buildings focused on sustainability and reducing carbon footprints.

· Neutral Light Grey Tint: The soft, neutral grey color of Super SHade enhances the look of any building, offering a sleek, modern appearance while maintaining excellent light transmission. The grey tint ensures both style and function without overpowering the design.

· Superior Light and Glare Control: Super SHade’s triple Low-E coating allows natural light to fill the space while minimizing glare and providing better light control, ensuring a comfortable indoor environment.

· UV Protection: Super SHade blocks harmful UV rays, protecting interiors from fading and damage caused by sunlight while maintaining bright, naturally lit spaces.

· Durability and Safety: Available in tempered and laminated options, Super SHade glass is designed to meet high safety and durability standards, ensuring it performs reliably in both residential and commercial applications.

· Optimal Clarity: Despite its high-performance coatings, Super SHade maintains crystal-clear views and transparency, making it an ideal choice for buildings with large glass facades or windows.

5mm-12mm per lite. Can be applied on laminated glass but coating must face the air spacer of an IGU.

ASG followed by overall thickness and Product name. Mention heat treatment heat strengthened or toughened and heat soaked.
