ASG Chrome Metal Glass

Makeup
6mm Clear + 12mm Argon spacer with Mesh + 6mm Clear Super D1-1#3

Performance Data

Gold

Visible Light Transmission: 41%

Solar Energy Transmission: 21%

U-Value (Winter Night): 1.36

U-Value (Summer Daylight): 1.27

Silver

Visible Light Transmission: 41%

Solar Energy Transmission: 21%

U-Value (Winter Night): 1.36

U-Value (Summer Daylight): 1.27

Bronze

Visible Light Transmission: 41%

Solar Energy Transmission: 21%

U-Value (Winter Night): 1.36

U-Value (Summer Daylight): 1.27

Maximum panel size: 2m × 4m.

Commercial and Residential Facades

Interior Partitions

Decorative Glass Panels

Windows and Doors

• Sophisticated Aesthetic: Chrometal glass incorporates an aluminium mesh between two layers of glass, creating a visually striking, metallic texture that adds a modern and industrial flair to any design.
• Superior Insulation: The double-glazed construction provides excellent thermal and acoustic insulation, helping to maintain comfortable indoor temperatures and reduce noise, making it ideal for both residential and commercial applications.
• Enhanced Durability: The aluminium mesh not only adds to the visual appeal but also reinforces the glass, increasing its strength and resistance to impact and wear.
• Privacy and Light Diffusion: The mesh within the glass offers a degree of privacy while still allowing natural light to diffuse through, balancing openness with discretion.
• Energy Efficiency: Chrometal glass contributes to energy savings by reducing heat transfer, helping to lower heating and cooling costs in both homes and offices.

• IGU glass is manufactured in compliance with AS/NZS 4666 – Insulating Glass Units
• Will need minimum of 25mm edge cover

Product Options:
Chrometal C1: A refined aluminum mesh with a clean, open diamond pattern, providing excellent visibility and light transmission.

Chrometal C2: A tightly woven aluminum mesh offering enhanced privacy while maintaining a sleek metallic finish.

ASG followed by DGU glass makeup and Chrometal, followed by mesh type. Mention heat treatment heat strengthened or toughened and heat soaked.
